4 days to an F-16 (wood)

In mid-April, I made a mistake: I downloaded a trial version of the Xbox360 game Ace Combat 6 in which you fly an F-16.

I called Levi down and showed him the game -- I expected him to want to fly the plane like he does on my computer (Microsoft Combat Flight Simulator 1, 2, 3); instead, Levi starts his "build me one out of wood" routine. Two weeks later I finally relented.

I decided to build it to 1:48 scale since I have a plastic F-16 model of that size that used to hang in Levi's room (he took it down to play with, so now it is in "daddy's museum" (or on a closet shelf out of little boy reach). I went online and found a set of plans for 1:48 F-16 wood model construction with the various variants, cross sections; in short, everything. All I needed was a top and side plan and we were good to go. While my initial thoughts were to take a piece of 2x4 to do the main body, after rummaging in my scrap wood pile I decided on a different tactic: I took a piece of 2x4 and sliced it down to make the main body, including rounding the nose. To get the curvature of the plane on the sides, I ran it on my combination disc/belt sander against the top roller of the belt sander -- with 60 grit sand paper, it quickly wore away a nice curve on the body. For the air intake and engine, I took a 1" dowel and sliced it down the middle, but left a chunk on one end. Back to the combo sander, this time using the disc sander to create an engine. For the cockpit, I actually took a square block, cut the main angles on the sides and the top, and then disc sanded it to round it up. Last came the wings and tail which comes from 1/8" scrap -- angles were cut on 12" bandsaw.

As you can see in picture with Levi, parts were rough sanded and were ready for gluing. Since this was going to be a play toy, I decided to make the wing one solid piece. In addition, I grooved out the underside of the body for the wing to attach and be flush with the body. On the bottom, the "air intake/engine" piece was attached with wood glue and a few strategically placed 5/8" brads were used to hold the body components together. Once they were set (60 minutes) I moved the clamps into a holding position and then attached the cockpit, tail components and the fins on the underside. By this time, Levi was asleep, so the airplane was able to dry very well over night.

The next challenge was what scheme to paint it - we did a search of F16 images on the internet and looked at hundreds of them. Levi decided this was the airplane he wanted. he called it the "dancing" chicken -- I believe it is a griffin. The cool thing for me was that it is a Danish aircraft, so there is some ancestral pride in trying to achieve this look.

Initial light color
First task after doing finishing sanding was to paint the "light" parts of the F-16, as well as get the color set for whatever that is on the tail. So I went with a light Testor's grey, and sprayed the key areas. I wasn't sure how well the paint would work since it is an oil based paint for plastic models, but it worked just fine. You might notice a little red on the cockpit: in the day or so that the aircraft was waiting to be painted, Levi drew a cockpit line because his plane was going to have 2 pilots. He was not happy I over sprayed it, but I promised to make the cockpit for 2 people.
Darker color

Next up was darker areas. I decided to mix a Testor's medium grey with a sea blue to give it a kind of blue/grey tint which I expected to feather into the lighter color, but be different enough to somewhat stand out. You might notice the tubing and such next to the F16 on the right; that is my spray gun. It is a standard Testor's spray gun, around $20 that is made to hook to a can of compressed gas. I've had thing for 20 years so now. Since I wasn't interested in shilling out the cash for the small cans of compressed gas, I decided to do a little modification to so that I could hook it to my air compressor. $4 in brass parts and 2 hours later (yes, it took me 2 hours sitting in a True-value store to get the right combination of parts that would work -- I wish I wrote down what made it successful!) I now am able to use my Kobalt air compressor to power my little sprayer. First thing I had to learn was to dial down the pressure. I now typically spray around 20 PSI tops.
Close up of dancing chicken

One happy owner
Now came the fun part -- how to get the tail art in place. I went back to the picture of the F16; it was reasonably in profile, so I loaded it into MS Office Picture Manager and scaled it up until it was 1:48 scale. Then I printed it out twice. One sharp x-acto blade, and 30 minutes later, I had cut out the art. Based on a previous, somewhat fiasco with a paper mask attempt, I decided to use a glue stick to temporarily attach the mask to the tail. I then masked off the rest of the plane, and using some red acrylic paint we had lying around from some other project, I painted the tail red. After a minute or so of set time, I carefully peeled the mask off, and was very pleasantly surprised at how well the detail came out. Finish painting included painting the cockpit white, and the obligatory stripe making it for 2 pilots.

While I was ready to start thinking of decals, Levi had other ideas -- he wanted to be able to see the pilot flying the plane. I spent a little time looking at potential pilots on the web, but did not find what I was looking for.

I knew Levi would expect to be able to see the face of the pilot from the front, and the side of their heads when they were viewed from the side. I couldn't find enough good pictures to let me do that. For a moment I thought of trying to paint something, but then an idea struck me: have Levi be the pilot and Lucy the other one.


Without telling them why, I had them sit down in front of the garage door, and I took a series of pictures. For Levi, I took one from the front, and then made him turn, and took a left and right profile picture. This would give me the necessary angles to meet his demands.

For Lucy, since she was going to be the back pilot, I decided to have her look at me for her left profile, and for her right profile, I took a picture of the back of her head (she had to think I was crazy).

Pilot detail
I then scaled the pictures down so they would fit on the cockpit, printed them out and cut them out. You can see the highlighting around Levi's pictures-- this was to help me see where to cut.

To attach them to the plane, I used Mod Page(r) glue them into place by putting some on the back and then a coat to seal on the top. Since I used a laser printer to print out the pictures, I had to be very careful not to smear their faces, but it still blurred a little.

For the Danish Air Force roundels and tail flag, since I did not have any in my scrap decals I went into MS PowerPoint and created them to scale with the various shape art. Similar to the "pilots", I printed them out on our Canon MP380 laser jet, and I used Mod Page(r) to glue them into place. For the plane numbering, Levi was fine with some decals I had that had letters followed by numbers. Once everything was in place, I put a few coats of Tamiya acrylic semi-gloss clear-coat to hold everything on. After one last night of drying, the aircraft was ready for flight. Levi and Lucy really enjoy being the "pilots".

Final aircraft, ready to fly

PS: Levi did a slight modification to the aircraft after production, that can be seen in the photo: the plane was missing the "flames" that come out of the engine, so he hot glued a stick in the hollowed out engine nacelle. Works great as a fly stick

Tuesday, April 5, 2011

2 Hours to an A10 Fairchild Warthog (wood)

Another month and another wood model. I don't seem to find the time to get out the plastic kit gear, and with a nice Friday/Saturday it was time to add to Levi's air force.

After looking around various pictures on the Internet, Levi settled in on the A-10 Fairchild "Warthog" (although my maternal line is Fairchild, the link to the aircraft company is way back in the family tree somewhere).

First task was to find a diagram to help guide the top/side/front layout. Next, Levi and I dug through the scrap wood bins to find the right wood for the job. We settled on a 2x4x10" pine for the body, 2x3/16" for the wing, 1.5x1/4" for the tails.rudders and engine mount and 1" dowel for the engine. 20 minutes was spent as I scaled out the drawing and transferred it to the wood with a few modifications to allow it to be more rugged.

After the transfer, it took about 20 minutes to rough cut all the pieces -- the trickiest part is the body. The picture at the left is before we slimmed down the body (from 1.5" thick to around 1.25" thick with a taper on the tail).

The other aspect was creating notches for the wing, engine mount and tail assembly to fit into the body. While I could have brought out my router table, I decided to do it the "old fashioned" way by making a series of close cuts that allow you to snap out which is a lot more fun for a 5 year-old than watching his dad set up yet another piece of machinery that kids can't touch.

So after trimming down the thickness, Levi went to work cleaning out the notches. He thought the clamps were a lot more fun to set than it was to take a file and smooth out the rough wood (I wondered when he got tall enough to stand at the wood horse comfortably to work away).

It took about 10 minutes of work to get the three notches cleaned out with most of the time going by as Levi worked out different ways to clamp the body down. After he had cleaned out the notches, I decided that the cockpit needed a little more shaping so I took out my wood chisels and proceeded to shape out the cockpit area.

The next phase was to finish the shaping and finish sanding. I will just say that there is no photo evidence that shows that I did not in fact do all the sanding on the combo belt/disc sander and that no 5 year-old was anywhere near a power tool with some wood and his fingers (nor will you find any other evidence of the use of a finishing gun driving 2" brads to hold the engines to the aircraft except for me). After sanding the pieces into the final shapes and doing finish sanding on the pieces it was time for assembly. This took about 15 minutes.

As mentioned earlier, I employed my air driven finish nailer -- the main wing was glued and then tacked in place with 5/8" brads, as were the engine mounts and the elevator and the tail fins (I thought it was nerve wracking nailing the fins into the 1/4" elevators without having a brad shoot out of the wood until I decided to attach the engines with 2" brads going into 1/4" thick engine mounts). For the engines, I had sanded one side of the dowel a little flat to give a better hold. I spread some wood glue and slightly slid the engine back-and-forth on the mount until it stuck. Not content just to have glue holding these things to the wood, I switched out the 5/8" brads and put in the 2" brads. First pull, 1 brad in, nothing sticking out. I mount the other engine the same way (glue, rub, stick, brad) but this time I get 1/2 the brad sticking out of the wood. I decide that each engine should have 2 brads, so in goes 2nd brad, and this time there's about 1/4" brad sticking out of wood. Arggh. Then Levi wants to put one more in the other engine. After making sure that all fingers are out of harms way, I line up the gun, Levi pulls the trigger .... perfection! No excess brad. Finally tally on the engine: Levi 1, brads 0; Eric 1, brads 2 (I am thinking I should have Levi do some more of my finish work!). This took us 20 minutes.

Now came the most difficult part -- getting Levi to leave the plane to dry overnight.

Early the next AM, Levi is ready to go. We went on the Internet looking for paint schemes. Originally he wanted a green plane, but then he saw a picture of one in more of desert camo that to him looked like yellow with browns. So we went through the scrap paint bucket (we buy a lot of the $1 Michael's wood kits that give you paint, and we put the excess paint into a bucket for use on various other fun things).

Levi went to work painting most of the body and top of the wings in yellow. He also decided to have the cockpit and nose blue so he painted those as well. I then talked him into painting yellow dots in various places to help with the camo. After painting the plane and some of his face yellow, Levi declared he was done and that I was to finish off the camo. I decided on a two-tone brown (one light, one dark) and proceeded to paint away. For some detail, we added black to the front/back of the engine nacelles as well as on top of the tail fin (per the picture we found on the Internet. He is a stickler for some details).

While the 45 minutes of painting was "forever" for Levi, it just about killed him waiting for the paint to dry. Once dry, Levi was quick to get the A10 aircraft ready for its maiden flight.

The beauty of this design is that just like the real aircraft, this model is squat, heavy and tough -- not too many delicate parts to get broken.

Sunday, March 13, 2011

3 hours to Apache 64 (wood)

Okay, I'd admit -- it's not a plastic model, but it is a 1:48 scale wood toy, so it does count! My  youngest son Levi has been after me for a few months to build him a wood helicopter, but with temps in Iowa being in single or negative digits and my "workshop" being in the unheated garage, I have taken a pass. Finally, last night, I decided it had been warm enough to give it a shot as the garage was a nice and balmy 40F. So at 8PM, I started the work. First up was getting the template ready. As I am currently working on a 1:48 scale Apache, I decided to use this as the model for Levi's helicopter (hoping he will let the model sit and look pretty). I dug around in my spare wood parts bin and found the perfect sized 2x4 to be the body of the model.

Making some allowances for the flight characteristics of a 5-year-old, I was ready to cut away. First, I cut out the outline on my trusty 1/2 horsepower Craftsmen band saw, and then I took off the sides to get the rough body shape. In the picture to the left you can see the plastic model body in the background, the roughed-out wood body. Not too bad for 30 minutes of work, is it? In the background is the 3/16" birch plywood leftover from a piano bench I made, that will become the roters.
Next up was the cutting out the roters. I decided for the sake of strength (and because I did not have a piece of thin plywood small enough) to make each "cross" piece as a whole, overlap them and then hold the whole assembly with a cap. (Actually, I was first thinking to take the cap and gluing each cross piece to it, but was stumped on how to make the whole thing rotate when I decided to turn the assembly upside down which is what you can see in the picture at the left.
Now came the "accessories": out of another piece of the birch  plywood scrap I fashioned out the rear roters and decided to make this a single assembly. I also found some 1/8" dowel which became the axle for the wheels and the gun. 2 pieces of 3/16" dowel became the axles for both roter assemblies. 1" dowel was used to create a cap for the rear dowel and the chin-gun assembly. All was cut out on the band saw, while the holes for the roters, axles and chin-gun were done on my Craftsmen drill press. Topping it off were some 1" wheels I had left over from a wood train I built for Levi. The picture at the right shows the dry assembled version with exception of the "engine" nacelles which are some scrap 1/2" plywood that are sitting behind the copter.

Now it was time to sand the parts and round off the edges. I was tempted to put much of it through my router, but decided instead to do all the rounding and shaping on my Craftsmen combo disc/belt sander. The cutting and sanding and fitting of parts took 2 hours.

Here are the parts ready to be assembled and there is also an excited Levi who can't wait. My idea on the roters was to glue the 1/4" dowel into the body of the craft, have the roters placed on the dowel, and then glue the cap on. Wheels would be done the same way with the axle running through the body and wheels glued on both ends. Trickier was the chin-gun - a 1/8" dowel was used as the mount, and a last minute decision by Levi turned the rotating chin-gun into a fixed mount weapon. Lastly the engines were glued to the side of the craft. In all, no nails or screw were used in this project.

The hardest part was gluing the top roters in an X without accidentally gluing them to dowel, body or cap. Some glue on a paper plate and toothpick made sure the glue only went were it needed to go. On the right is the "finished" helicopter waiting to solidify overnight. Since I had used a scrap piece of 2x4 that had spent some time outside, I took a little time to infuse the various splits with some glue to prevent the body from splitting apart.
After the glue had about 10 minutes to set, the new toy was put through its maiden flight, and I am proud to report that no mishaps -- major or minor -- occurred. Levi ordered the copter to be unpainted, so after drying all night, he took permanent possession this morning. With some hot glue help from his mom, he added some eyes, and then he applied some camouflage using Crayola Dot paint -- blue of course. Pilot has already logged 2 hours flight time and was able to walk away from a crash with no damage!

Sunday, September 26, 2010

4 hours to "Arado 240" (wood)

While I intend this site to be about building plastic model aircraft, I did a quick project last Friday/Saturday that was a lot of fun.

One of the models I am working on is a Revell of Germany Arado 240C . Knowing my 4 year-olds desire to play with models and looking at some scrap wood in my garage, I hit upon the idea to build him a similar aircraft out of wood that would be durable. So at 9:30 PM on Friday night, I started my project.

 First off, I planned this to be a quick easy job -- so it was 5 minutes of scanning the drawing from the plastic kit to get a plan, and then finding the right wood from my scrap. I settled on a couple of pieces of 1/4x2 in for the wings and tail assembly, a 1/2 x2 in for the body (actually 3/8x1 3/4), and a piece of 3/4 dowel for the engines. Not show is the 1 1/2 dowel piece used for the flying propellers. My goal was to build a descent size aircraft without it being to heavy and cumbersome for Levi to fly. Final dimensions of the aircraft would end up being 10 1/2 in. at the wingspan and about 9 1/2in body length.

Next step was to transfer the plan to the wood which was pretty simple since I was using pine scraps: I just placed the plan on the wood, and traced it -- it made a  nice indention for the me to trace directly on the wood.


Next up was to do the rough cutting with my trusty 12" Craftsman bandsaw: I first cut the wing, then the tail wing, followed by the engines, the tail fins and then the body. Notice I left some room around the tracings so as I worked the wood toward the finish it would be become more true. I also did not do the cut down on the rear fuselage or the engines as this is easy enough to do with pine (as it is a very soft wood) when run against the Craftsman bench sander.

All told, the cutting probably took 30 minutes.

For the finish work, I used my trusty Craftsman bench sander which has a combination belt sander and disc sander.

For the initial work on the wings, tail assembly and body, I used the belt sander which is running 60 grit. You'll notice that the rear section now tapers. What can't be seen in the photo is that I sanded down the tail fins about 40% from their original thickness, and on the wings, they are tapered to be thicker from front to back. I had to do this because Levi knows that airplane wings are thicker from front to back and he would question me incessantly why this airplane didn't have "real" wings. I used the disc sander (120 grit) to do 'finish' sanding on the everything, and to shaper down the engines to that they have a slight taper in the front, and sharp taper in the back. All told, this took about 45 minutes of work.

As with this type of project I took a couple of liberties: (1) I put the engines on top of the wing as this would make the bottom level and more sturdy to withstand the turbulent flights it would experience; (2) I didn't put the fin on the rear of the fuselage either -- didn't feel like taking the time.

With everything pretty much good to go, it was back to the band saw to cut out the notch on the bottom of the engines. I did this nifty trick when you make a series of vertical cuts, close to together, and then you break out the pieces by rubbing them on a sharp edge (should take a picture) and clean it up with a chisel. All told, in 10 minutes, both engines were notched and ready for permanent fitting.

I then cut two "flying" propellers out of the 1" dowel about 1/8 in thickness, and drilled holes in the middle.

Then it was time for gluing the parts together, and to help keep everything in its place, I used 5/8 in brads from my nail gun to help hold the parts together (most nerve wracking part was nailing the tail fins in place and expecting to see a brad come through the tail wing, but all went perfect). At the end of Friday night at 12:30 AM, the aircraft was set to dry.

Saturday morning, there was an excited Levi with the aircraft. Barely was it in his hands and then he was asking to paint it black, as he knew from looking at the Arado 240C model that this plane was black on one side "so it is invisible at night" as Levi told me.

Levis is a very good and exacting painter (especially for a 4 year old). Here he is with the bottom of the plane painted black waiting to dry so the top can be painted grey. We used some spare black house paint (don't ask, but it deals with a teenage boy) for the bottom, and then mixed the black with some exterior tan paint to make the grey. Levi had me paint the top as he didn't want the grey to run on to the black, and it is nothing like painting as fast,  yet carefully, as you can with a 4 year old task master. After the grey was put it, then we mixed more black into the grey to make a darker grey so we could apply "polka dots" as Levi called them. I had Levi paint them on after showing him how to dip the brush in the paint, dab it on a paper towel, and then dab his plane.

As the paint dried, we went through my collection of decals from planes long gone. Levi decided he wanted stars and picked out some red stars from a long gone MiG-21 kit, to which he added some red 4's (because he is 4) from a Panzer IV kit, some yellow stripes from a F-86 Saber kit, and then on the nose he picked out a bat/card motif from a F-111 kit. After I applied these for him, we had to take a detour and have me paint a place for the pilots to sit, so on went the white paint for the cockpit (extra from some wood projects the girls do).

Final touch was to seal the decals and the paint with Testors semi-gloss paint. After about an hour of drying, Levi's plane was finally permanently in the skies.

All told, the aircraft took about 4 hours of human effort with about 12 hours of various drying times. Levi is already lining up the next airplane he wants me to build, which he promises will be BIG!
